Manual Lathe CW6291B/62100B/62110B
, ,

Manual Lathe CW6291B/62100B/62110B

The surface of the bedways is supersonic frequency handened.Rapid feed structure is available on apron. Clutch in headstock makes the lathe start smoothly and brake quickly.

Categories: , ,
Item Unit CW6291B CW62100B CW62110B
Processing
Max. swing Dia. over bed mm Ф910 4000 Ф1100
Max. swing Dia. over carriage mm Ф580 Ф580 Ф680
Max. swing Dia. in gap mm Ф1100 Ф1200 Ф1300
Width of bed mm 600 600 600
Max.length of workpiece mm 1500/2000/3000/4000/5000 1500/2000/3000/4000/5000 1500/2000/3000/4000/5000
Maximum turned length mm 1350/1850/2850/3850/4850 1350/1850/2850/3850/4850 1350/1850/2850/3850/4850
Effective length of gap mm 400 400 400
Max. Weight of work piece(between centers) kg 2000 2000 2000
Spindle
Spindle nose D11 D11 D11
Spindle bore mm Ф105 Ф105 Ф105
Taper of bore Metric Ф120 1:20 Metric Ф120 1:20 Metric Ф120 1:20
Step of spindle speed
 18 18 18
Range of spindle speed
 rpm 5~720 5~645 5~645
Pitch & Dia. of longitudinal ball screw
 mm 12/Ф55 12/Ф55 12/Ф55
Feed 64 64 64
Range of feeds
Range of longitudinal feeds(1:1) r/min 0.1~1.52 0.1~1.52 0.1~1.52
Range of longitudinal feeds (16:1) r/min 1.6~24.3 1.6~24.3 1.6~24.3
Number of cross feeds 64 64 64
Range of cross feeds half of longitudinal feeds half of longitudinal feeds half of longitudinal feeds
Thread cutting
Metric range/No. 1~240mm/50 1~240mm/50 1~240mm/50
Inch range/No 14~1T.P.I/26 14~1T.P.I/26 14~1T.P.I/26
D.P.Range/No. 28~1D.P/24 28~1D.P/24 28~1D.P/24
Module range/No. 0.5~120M.P/53 0.5~120M.P/53 0.5~120M.P/53
Rapid traverse
Longituding mm/min 4000 4000 4000
Cross mm/min 2000 2000 2000
Tailstock
External Dia. mm Ф100 Ф100 Ф100
Taper of bore M.T.No.6 M.T.No.6 M.T.No.6
Max. traverse mm 250 250 250
Vertical distance from spindle center to installing basis mm 33 33 33
Max.travel of compound rest mm 200 200 200
Swing angle of tool post
Deg.
 ±90 ±90 ±90
Max. cross slide travel mm 500 570 620
Max. size of tool shank (W×H) mm 32×32 32×32 32×32
Power of main motor kW 11 11 11
Rapid feed motor power kW 1.1 1.1 1.1
Coolant pump power W 90 90 90
3m machine overall dimensions(L×W×H) mm 5155×1450×1630 5155×1450×1685 5155×1450×1735
3m Net weight kg 7050 7550 8050
